Wentzville Bluffs

CLIENT – CapDev, LLC

Cochran has provided full service civil design and survey services for an approximately 27 acre commercial development project located in the southwest corner of the intersection of Hwy 70 and Hwy Z in Wentzville, Missouri.  The survey services included boundary, easement, topographic and ALTA surveys along with construction staking services.  Engineering included design of six infrastructures including roadways, water mains, sanitary sewers, storm sewers and grading.  The engineering services also included site specific design for B&B Theaters, Planet Fitness, Hotshots, Summit Steak House, 6 North Cafe, Hampton Inn, and Lot 8 Retail.  The project also included engineering and surveying to widen Hwy Z for a turn lane per MoDOT Standards.  One lot remain open and available and Cochran is providing engineering and surveying services as needed until full development is complete.

Tiger Express Wash

CLIENT – Coil Construction

Since 2010, Cochran has teamed with Coil Construction for a number of large commercial projects.  Most recently, we are providing site/design for the construction of Tiger Express Wash facilities.  Services being provided include: conceptual planning, survey, engineering, and permitting.

Pictured below, the Farmington store, completed construction and opened for business in May, 2018.  This 1.12 acre site, located at 1286 Maple Street, was previously a vacant lot.  Cochran completed an ALTA/NSPS Land Title, Property Boundary and Topographic Survey for this site.  Professional services included preliminary site planning, preparation of construction documents & landscape plan, layout revisions, and MDNR Land Disturbance Permitting.

To-date, Cochran is currently providing civil design services for 9 new car wash locations throughout Missouri and Kansas.

MERS Goodwill

CLIENT – MERS Goodwill

Established in 1918, MERS Missouri Goodwill Industries is a non-profit organization that provides employment rehabilitation services.  Most funds are received via their 44 retail locations/donation centers and are used to facilitate their mission… “Changing lives through the power of work”.

Since 2010 Cochran, has worked with MERS/Goodwill to construct new stores and upgrade existing facilities.  As part of our scope of services, Cochran has completed, or is currently providing full service professional civil engineering, surveying, geotechnical, and materials testing services for more than 38 MERS/Goodwill stores throughout the Midwest and Illinois.  Upgrades to the existing facilities have included the addition of new truck docks, ADA compliance upgrades, and parking lot improvements.  The new stores included conceptual planning, boundary and topographic surveys, geotechnical services, Phase 1 ESA services, Planning and Board approvals, civil construction plan preparation, permitting, construction staking, construction material testing and as-built surveys.  The new retail locations have included stores ranging from 11,000 S.F. to 15,300 S.F. and all associated parking, storm sewers, sanitary sewers, water service, detention, etc.

Suntrup Hyundai

Client – Suntrup Hyundai

Cochran provided survey and engineering design services for this 3.4 acre car dealership.  The project design included grading, pavement, storm sewers and utilities to serve the new project site.  The design also included retention basins to accommodate water quality, channel protection and storm water detention, according to the City’s requirements.

Walmart & Market at Water Tower Place

Client – Wal-Mart Stores, Inc. & Water Tower Development LLC

The scope of the project included an on-site relocation of a 128,000 s.f. Walmart store and a new 204,000 s.f. Walmart Supercenter was constructed adjacent to the existing Walmart store in Arnold, MO.  The new store construction consisted of complete removal and replacement of the existing parking lot and associated utilities.  The project included several complicated phases which allowed the Walmart stores to remain open every day during the duration of the project.  The new store opened the day after the existing store closed.  The parking lot for the adjacent Church of Christ was relocated to make room for the new Walmart building and parking lot.  The reconstruction of the church parking lot included the construction of a 30 foot tall modular block retaining wall.

The project also included two Strip Retail Outlot Developments adjacent to the Walmart.  The Market at Water Tower Place contains Shoe Carnival, Visionworks, OrangeLeaf, SportClips, and Five Guys.  Our Architecture department designed the second phase which currently includes McAlister’s Deli and AT&T.  Cochran performed all of the civil design for the entire complex projects.

Walgreens

Client – Multiple Developers

Cochran performed all aspects of civil site design including conceptual layouts, land surveying, city approvals, permits, grading, utilities, landscaping, stakeout, and construction plans and specifications for multiple Walgreen stores located in Missouri.

Veteran’s Care

Client – Veteran’s Care

Cochran was selected to design the 15,000 sf tilt-up office and warehouse steel structure addition of which 5,000 sf included complete tenant finishing. Cochran services included architecture, civil, and interior design along with geotechnical and survey services. The floor plan included open floor space, traditional office, conference and training rooms, two new full restrooms and an employee lunchroom with outdoor seating.

In the lunchroom, we were able to utilize some unique design elements. The existing building had a large industrial overhead door. By switching out the existing door for a new fire-station type door with glass, we were able to introduce day lighting for the lunchroom. This also allowed the owners to open the door and use the new patio on the exterior for an open indoor/outdoor area. The new finishes selected, complimented the existing finishes and brought earth tones to compliment their open concept design.

State Farm

Client – State Farm

Cochran was selected to design State Farm’s new 9,000 sf, 2 story loft office building and training center which includes space for four additional tenants with separate entrances.  Cochran services include architectural, interior and engineering design, along with survey, geotechnical and construction administration.

Located in close proximity to an existing residential area and on a compact site, the unique challenge was to blend the commercial building with the adjacent residential area. The building is a combination of wood and steel and brick and stone facade.

Prewitt’s Point

Client – Prewitt Enterprises

Cochran was selected to provide civil design, survey (boundary, platting and topography) and geotechnical services for this 160-acre retail/commercial project located along Missouri Route 54 in Osage Beach, Missouri.

The project included 3 big box stores, multiple small box, retail strip and outlot users.

Some of the tenants include Hy-Vee, Target, Lowe’s, Marshalls, Petco, Walgreens, Jo-Ann Fabric, Ross Dress for Less, Outback Steakhouse, West Marine, Steak ‘n’ Shake, Shoe Carnival, and Maurices.

Cochran has performed consulting services for this development for over 15 years.

The Shoppes at Eagles’ Landing

Client – Prewitt Enterprises

Cochran was selected to provide all civil design, survey, and geotechincal services for the 150-acre Eagles’ Landing project located along Missouri Route 54 Bypass in Lake Ozark, Missouri. Eagles’ Landing is Lake Ozark’s premier retail shopping center.

Scope of services included master planning, extensive mass grading, roadway and access design, wet and dry utilities.  Due to the project location, challenges includes cuts and fills of 65 to 100 feet. Geotechnical concerns included settlement due to the weight of the new fill, high plastic soil, uncontrolled rubble fill and excavation of rock.

Some of the tenants include CVS Pharmacy, Buffalo Wild Wings, Kohls, Menards, Wehrenberg Eagles’ Landing 8 Cine Theatre.

Heritage Community Bank

Client – Heritage Community Bank

Cochran worked with the owner and contractor from conceptual through construction on this design build project to upgrade the facade of the 40+ year old shopping center.

Emphasis was given to the end suite for the anchor tenant and new owners, Heritage Community Bank. Some of their main goals for the project were to have better visibility from the highway and give the center new life with an updated color scheme and more modern finishes. Cochran surveyed the building including existing structure to ensure the new facade would be properly stabilized and supported. A new skin was put over the existing metal facade and new paint on the existing brick. In the end, the shopping center stands out at this busy intersection bringing new attention to a once forgotten strip center.

Providence Bank

Client – Providence Bank

Providence Bank, headquartered in Columbia, Missouri, provides personal and banking services in Missouri, Illinois, and Texas.

Cochran has worked closely with Providence Bank for site development and improvements for several locations.   In 2014, Cochran teamed with Providence Bank and provided civil design services for a new banking center at 460 Hawk Ridge Trail, Lake St. Louis;  a 2,500 square foot state-of the-art, full service bank featuring two drive-thru lanes, a drive-up ATM.

Professional services for this location include topographic survey, preliminary site planning for client and City Planning and Zoning approval, permitting, preparation of construction documents for grading/SWPPP, storm sewer system, pavement, sanitary sewer, water, and landscaping plans.  Moving forward though the construction process, Cochran provided shop drawing reviews, staking, materials testing & inspection services, and as-built survey.

Coil Construction served as General Contractor.  Project completed with bank opening April, 2016.

Fricks Market

Client – Fricks Grocery Store

With a commanding view over the City of Union, the new 35,000 square foot Fricks’ Market is designed to enhance the customer experience, while placing the customer’s needs first.

Fricks, a family-owned grocery store with two locations in Missouri, selected Cochran for relocation and design of their new 35,000 square foot store. Cochran’s interior design features rich, bold colors and theme designs for the bakery, liquor and meat & seafood departments. The highly popular deli department was expanded to include a mezzanine cafe area, and convenient drive thru for customer flexibility. Keeping sustainability in mind, Cochran utilized natural exterior materials to compliment the surrounding buildings and landscape, and utilized reclaimed heat to warm the warehouse. Future plans call for a waste oil (cooking oil) furnace to increase the overall sustainability of the market.

The design defining corner tower anchors the south side of the building increasing hilltop visibility and notoriety for this new location. Daylighting, energy efficient lighting, HVAC systems, refrigerator and freezer units were specially selected to increase energy efficiency.

The compact site required multiple retaining walls and underground storm water retention for environmentally efficient and fast storm water removal. The limited footprint demanded strategic placement for delivery truck traffic to reduce customer/delivery traffic conflicts.

Cochran services included architecture, interior, civil, and engineering design, survey, construction testing & inspection and construction observation/administration.
